IY190175,Inductive sensor,tube 19x87,5x9,static, 10-30V DC,200mA,Sn:10,M8-plug, IPF ELECTRONIC

Availability: at an end

Dispatched within: 4 days

Delivery: check the delivery methods

Price: €105.51

excl. 23% TAX, excl. shipping costs

Regular price:

105.51

The lowest price during 30 days prior to the reduction:

quantity pcs

product unavailable

add to wish list

Rating:

Vendor:

Product code: IY190175

Description

Inductive proximity switches are contact-free sensors. They detect all conductive metals, regardless of whether they move or not. The achievable sensing range of the devices depends on the object material and its dimensions. The vibration-resistant sensors can be approached laterally or frontally. Inductive proximity switches are used for presence detection (e.g. goods carriers), positioning (e.g. dampers), counting (e.g. nuts /bolts), speed detection (e.g. for cog wheels), on conveyor systems (e.g. hose feedings) or distance measurements (e.g. press-in checking) of metallic objects.

Circuit diagram: Link

Colours: 1 = BN (brown), 3 = BU (blue), 4 = BK (black) Functions: 1 = L+, 3 = L-, 4 = PNP NO

Files to download:

Technical data

design	cuboid
length	9mm
ring height	78.5mm
ring width	19mm
housing material	PA 6.6 (synthetic)
IP system of protection	IP67
sensing range	10mm
mounting	non-flush
connection	connector M8
output	PNP
output function	normally open contact
ampacity	200mA
voltage type	DC
ambient temperature	-25 - 75°C
